Introduction

The structural design of steel structures is one of IMK’s core activities, and largely the responsibility of our Design Department (OE GK). IMK delivers comprehensive designs for steel structures or the design of a certain phase, according to specific customer needs and requirements. Regardless of the scale or extent of the order, IMK knows that quality project documentation is very important in avoiding any unforeseen or additional manufacturing and execution costs. Due to our extensive professional knowhow, our project references include some of the most important and demanding steel structures in Slovenia and the larger region.

Structural designs are further elaborated as below:

Head of the Design Dept.

gregor.gruden@imk.si

+386 1 280 21 16

+386 41 634 677

Gregor Gruden

The Hradeckega bridge (revitalized cast iron bridge) at its new location in Trnovo, Ljubljana;

Gas pipeline and pedestrian bridge over HPP Channel at Zlatoličje.

Types of project documentation:

  • preliminary concepts (IDZ),
  • preliminary designs (IDP),
  • tender designs (PZR),
  • building permit designs (PGD),
  • manufacturability design (PZI),
  • as-built design (PID).

Static calculations and numerical structural analysis:

  • static and dynamic structural analysis of buildings, road and railway bridges, industrial, energy and infrastructural structures according to Eurocodes,
  • structural fire design analysis (“hot design”) according to Eurocode EN 1993-1-2.
Design reviews and audits:

  • buildings,
  • road and railway bridges,
  • industrial, energy and infrastructural structures.

IMK business partners:
Most of our clients in the field of design are longer-term business partners, who are well aware that quality project documentation is essential for a successful investment project.

aAAAAIndustrial objects

asdfa
sdf
as
df
asdf
asdf

  • Overpass over railroad and pedestrian bridge over the Grubar channel (2013), PGD, PZI, PID
  • Road Bridge restoration over Sava river in Črnuče (2013), IDZ, PZI
  • »Rafter’s” footbridge in Celje (2013), PZI
  • Casting hall building Reconstruction Metal Ravne – new 130 t overhead crane (2013), PZI statical design
  • Goodyear Dunlop Sava tires warehouse building (2012), PGD, PZI
  • Railroad bridges repair design Pragersko – Ormož – Hodoš – d.m. (2012), PZI
  • Kočevje stadium stands (2012), PZI
  • Delavski bridge in Kranj repair design (2012), PZI
  • Blooming Acroni Jesenice building reconstruction– new 145t overhead crane (2011), PGD, PZI, PID
  • Furnace and casting hall building reconstruction Acroni Jesenice – new 135t in 200t overead cranes (2011), PZI statical calculation
  • Manufacturing hall building reconstruction Monter Dravograd – new 20t overhead crane (2011), PZI
  • New production hall for ESR device Metal Ravne (2011); PGD, PZI, “hot design”
  • Gantry crane calculation HE Dravograd (2010)
  • Road bridge over Sava river in Tacen repair design (2010); PGD, PZI
  • Cast iron »Dead man’s bridge« in Ljubljana reconstruction (2010), PGD, PZI
  • Gas pipeline bridge Zlatoličje (2010); PGD, PZI
  • Main departures building Zvartnots, Yerevan, Armenia (2010); PGD, PZI statical and dynamical design
  • Reconstruction and optimisation of continous casting device structure (2009); PZI
  • Striper hall Acroni Jesenice rekonstruction (2009); PGD, PZI, PID
  • Podčetrtek sports hall (2009); PGD, PZI
  • OŠ Cvetka Golarja sports hall in Škofja Loka; »hot design« (2009)
  • Multipurpose sports hall Kranj; »vroči račun« (2008)
  • Veszprem Arena sports hall, Hungary (2008); PGD, PZI
  • Road bridge over Ljubljanica river in Podpeč (2007); PGD, PZI
  • Wood mass containet structure in TE-TOL Ljubljana (2005); PGD, PZI
  • Dismantable bridges Mabey C200 type– statical calculations
  • New Steklarna Hrastnik plant buildin (2005); PGD design review, PZI, “hot design”
  • Road bridge over Krka river in Dvor repair design (2004); PZI
  • Mercator center mall Djakovo, Croatia (2004); PZI
  • Mercator center mall Celje with Multiplex cinema (2003); PZI
  • Mercator center mall Split, Croatia (2002); PGD
  • New technologies building – development, research and testing EMO Orodjarna Celje (2002); PGD, PZI
  • Cerkvenikov bridge over Hanke canal in Škocjanske jame (2001); PGD, PZI
  • BSN Beziers bottle factory (2000); PGD, PZI
  • Reconstruction (replacement and widening) of the road overpass over railroad in Trebnje (2000); PGD, PZI
  • Car salon INTEGRAL Jesenice (2000); PZI steel structure
  • Turbine building in TE Brestanica; PZI
  • Bridge over Sava in Radeče repair design (1998); PGD, PZI
  • Railway bridge over Sava river in km 538+019 right track Zidani most – Ljubljana line (1998); PZR, PGD, PZI
  • Road bridge over Ljubljanica in Vrhnika on the R-324 road (1997); PGD, PZI
  • Bridge over Dravinja river at Zbelovo revitalization and repair design (1995)
  • Road viaduct Završnica on M-1 repair design (1994); PZI
  • Road bridge Kandija in Novo mesto repair design (1994); PGD, PZI
  • Railroad bridge over Sava river in Zalog in km. 557+225 Dobova-Jesenice line(1992)
  • Suspension pedestrian bridge over Sava river in Renke (1991); PGD, PZI

  • Daljnovod 110 kV Maribor – Cirkovce (2013), recenzija
  • Bazne postaje Telekom (2013), recenzije izbranih mest
  • PZI sanacije vodovodnega sistema OIL (2013), recenzija
  • Stadion in športna dvorana Stožice (2012), recenzija
  • Prostor za mobilno opremo NEK (2012), kontrolni statični izračun – revizija
  • Most čez Savo v Martuljku (2009); revizija
  • FRI in FKKT – “Objekt X” (2009); revizija
  • Brv čez Grubarjev kanal na Špici (2008); revizija
  • Mednarodni mejni prehod Zavrč (2007), revizija
  • Razširitev jeklarne Acroni Jesenice – Hala vložka (2007); revizija
  • Hangar za vzdrževanje Airbus- Adria Brnik (2005), recenzija
  • Vhodna avla Iskratel Kranj (2005), revizija
  • Steklarna Hrastnik – nova tovarna (2005); PGD revizija, PZI, “vroči račun”
  • Hangar male aviacije na Aerodromu Brnik (2004); revizija
  • Supernova Koper (trgovski center, vezni most, OBI, fasada) v Kopru (2002); revizija
  • Nadzidava OŠ France Prešeren v Kranju (2002); revizija
  • Bencinski servis AGIP Rudnik v Ljubljani (2002); revizija
  • Distribucijski center Sava Tires v Kranju (2001); revizija
  • Betonarna BAUMIX II 2.0/150 CM Celje, baza Pirešica (2001); nostrifikacija – revizija PGD statike
  • Regalno skladišče v skladišču ND Petrol Zalog (2000); nostrifikacija – revizija PGD statike
  • Regalno in paletno skladišče v novi tovarni hladilnikov Gorenje v Velenju (2000); nostrifikacija – revizija PGD statike

Industrial structures:

Static design and project documentation – selected examples.

Bridges:

Static design and project documentation of steel and composite bridges.

Sports facilities:

Other structures:

Static and dynamic design of the main departures building at Zvartnots airport (Yerevan, Armenia).
